Hey guys! Today, let's dive into a structural mechanics problem that's super common in engineering: calculating the maximum compressive stress caused by bending. This is a crucial concept for anyone working with structural design, civil engineering, or any field where you need to understand how materials behave under load. We've got a specific scenario here with a bending moment, moment of inertia, and section height, so let's break it down step by step. Understanding maximum compressive stress is essential in structural engineering. This parameter helps engineers ensure the structural integrity and safety of various constructions. When designing structures, it's vital to accurately calculate the stresses that materials will experience under different loading conditions. Ignoring these calculations can lead to catastrophic failures, endangering lives and causing significant economic damage. Accurately determining the maximum compressive stress allows engineers to select appropriate materials and dimensions for structural members, ensuring they can withstand the applied loads without failure. For instance, in bridge construction, engineers must carefully calculate the compressive stresses in concrete piers and steel beams to prevent collapses. Similarly, in building design, the compressive stresses in columns and walls must be meticulously evaluated to ensure the structure can support its weight and any additional loads, such as wind or seismic forces. Furthermore, understanding compressive stress is not only crucial for new constructions but also for assessing the condition of existing structures. Over time, structures may degrade due to environmental factors, material aging, or increased loading conditions. Assessing the remaining compressive strength of structural components is essential for determining the need for repairs, reinforcements, or replacements. This proactive approach helps prevent unexpected failures and extends the lifespan of the structure. In addition to preventing failures, optimizing the use of materials is another significant benefit of accurately calculating compressive stress. Over-designing structures can lead to unnecessary material costs and increased construction time. By precisely determining the required strength and dimensions, engineers can minimize material usage, reducing both the environmental impact and the cost of the project. This optimization is particularly relevant in large-scale projects where even small material savings can translate into significant cost reductions. Moreover, the principles of compressive stress calculation extend beyond traditional civil engineering applications. They are also essential in mechanical engineering, aerospace engineering, and even biomedical engineering. For example, in mechanical engineering, understanding the compressive stresses in machine components is crucial for designing durable and efficient machinery. In aerospace engineering, the compressive stresses in aircraft structures must be carefully analyzed to ensure the safety and performance of the aircraft. Similarly, in biomedical engineering, the compressive stresses in implants and prosthetics must be considered to ensure their long-term functionality and compatibility with the human body. Therefore, a thorough understanding of compressive stress is indispensable for engineers across various disciplines. It forms the foundation for safe, efficient, and sustainable designs, ultimately contributing to the well-being of society and the advancement of technology. In the following sections, we will delve into the specific problem at hand, breaking down the steps required to calculate the maximum compressive stress and highlighting the underlying principles and formulas. This practical application will help solidify your understanding and equip you with the skills necessary to tackle similar challenges in your own engineering endeavors.

Problem Statement

Okay, here's the problem we're tackling: Given a bending moment (M) of 5000 kN.cm, a moment of inertia (I) of 22500 cm^4, and the height of a rectangular section (h) of 30 cm, we need to find the maximum compressive stress caused by bending. We've got some answer choices too, ranging from -4.33 kN/cm^2 to -7.33 kN/cm^2. So, let's roll up our sleeves and figure this out! To successfully solve this problem, it's crucial to first understand the key concepts and formulas involved in calculating bending stress. Bending stress, also known as flexural stress, arises when a structural member is subjected to a bending moment. This moment causes the member to deform, resulting in tensile stress on one side and compressive stress on the opposite side. The magnitude of these stresses varies across the cross-section of the member, with the maximum stress occurring at the farthest points from the neutral axis. The neutral axis is an imaginary line within the cross-section where there is neither tensile nor compressive stress. For a symmetrical section like a rectangle, the neutral axis is located at the centroid, which is the geometric center of the section. The moment of inertia (I) is a geometric property that quantifies the resistance of a cross-section to bending. A higher moment of inertia indicates a greater resistance to bending, meaning the section can withstand larger bending moments without experiencing excessive stress. For a rectangular section, the moment of inertia is calculated using the formula I = (b*h^3)/12, where 'b' is the width of the section and 'h' is the height. However, in this problem, the moment of inertia is already provided, so we don't need to calculate it. The bending moment (M) is the internal moment within a structural member caused by external loads. It is a measure of the bending effect at a particular section of the member. The bending moment is typically expressed in units of force multiplied by distance, such as kN.cm in this case. The maximum bending stress (σ_max) is the highest stress experienced by the material due to bending. It occurs at the extreme fibers of the section, which are the points farthest from the neutral axis. The formula for calculating maximum bending stress is given by: σ_max = (M * y) / I where: - σ_max is the maximum bending stress - M is the bending moment - y is the distance from the neutral axis to the extreme fiber - I is the moment of inertia In this problem, we are given M = 5000 kN.cm, I = 22500 cm^4, and h = 30 cm. Since we are looking for the maximum compressive stress, we need to consider the distance from the neutral axis to the extreme compressive fiber. For a rectangular section, this distance is half of the total height, which is y = h/2 = 30 cm / 2 = 15 cm. Now that we have all the necessary values, we can plug them into the formula to calculate the maximum compressive stress. By carefully applying this formula and understanding the underlying concepts, we can accurately determine the stress experienced by the material and ensure the structural integrity of the design. In the next section, we will proceed with the calculation and arrive at the solution.

Solution

Alright, let's get down to business and solve this thing! We're going to use the bending stress formula: σ_max = (M * y) / I. Remember, M is the bending moment (5000 kN.cm), y is the distance from the neutral axis to the extreme fiber (which is half the height, so 30 cm / 2 = 15 cm), and I is the moment of inertia (22500 cm^4). Let's plug in those values: σ_max = (5000 kN.cm * 15 cm) / 22500 cm^4. Now, let's do the math: σ_max = 75000 kN.cm^2 / 22500 cm^4. Simplifying this, we get: σ_max = 3.33 kN/cm^2. But wait! We need the compressive stress, and compressive stress is negative. So, the maximum compressive stress is -3.33 kN/cm^2. And that matches option (B)! The process of calculating the maximum compressive stress involves several key steps, each requiring careful attention to detail to ensure accuracy. The first step is to identify and gather all the necessary parameters from the problem statement. In this case, we are given the bending moment (M), the moment of inertia (I), and the height of the rectangular section (h). These parameters are crucial inputs for the bending stress formula, and any error in these values will directly affect the final result. Once we have identified these parameters, the next step is to determine the distance from the neutral axis to the extreme compressive fiber (y). For a symmetrical section like a rectangle, the neutral axis is located at the centroid, and the distance to the extreme fiber is simply half of the total height. This simplifies the calculation and reduces the likelihood of errors. The most critical step is applying the bending stress formula: σ_max = (M * y) / I. This formula is the cornerstone of bending stress calculations, and it directly relates the bending moment, distance from the neutral axis, and moment of inertia to the maximum stress experienced by the material. It's essential to ensure that all the values are in consistent units before plugging them into the formula. In our case, all the values are in centimeters and kilonewtons, so we can proceed directly with the calculation. After substituting the values into the formula, we perform the arithmetic operations to arrive at the numerical result. In this specific problem, we calculate σ_max = (5000 kN.cm * 15 cm) / 22500 cm^4, which simplifies to σ_max = 3.33 kN/cm^2. However, it's crucial to remember that we are looking for the compressive stress. Compressive stress is conventionally represented as a negative value, while tensile stress is positive. Therefore, we need to apply the correct sign to the calculated stress value. Since we are looking for the maximum compressive stress, we assign a negative sign to the result, giving us σ_max = -3.33 kN/cm^2. This step is vital to ensure that the final answer accurately reflects the physical situation and the type of stress being experienced by the material. Finally, it's always a good practice to compare the calculated result with the given options or expected range to verify its reasonableness. This helps catch any potential errors in the calculation process. In our case, the calculated value of -3.33 kN/cm^2 matches one of the given options (B), indicating that our solution is likely correct. By meticulously following these steps and paying close attention to the details, we can confidently determine the maximum compressive stress in a bending scenario and ensure the structural integrity of our designs.

Answer

So, the answer is (B) -3.33 kN/cm^2. We nailed it! Calculating maximum compressive stress is a fundamental skill in structural engineering, and this problem really highlights the key steps involved. Remember the formula, keep your units consistent, and don't forget the sign convention for compressive stress! In addition to mastering the calculation of maximum compressive stress, it's also essential to understand the factors that influence this stress and how they interact with each other. The bending stress formula, σ_max = (M * y) / I, clearly shows the relationship between the bending moment (M), the distance from the neutral axis to the extreme fiber (y), and the moment of inertia (I). Let's delve deeper into each of these factors and their impact on the maximum compressive stress. The bending moment (M) is a measure of the internal forces within a structural member caused by external loads. A larger bending moment indicates a greater bending effect, which directly translates to higher stresses within the material. Therefore, increasing the bending moment will increase the maximum compressive stress, and vice versa. The bending moment depends on several factors, including the magnitude and distribution of the applied loads, the support conditions, and the geometry of the structural member. For example, a simply supported beam with a concentrated load at the center will experience a different bending moment distribution compared to a cantilever beam with a uniformly distributed load. Understanding how different loading conditions affect the bending moment is crucial for accurately calculating the stresses in a structure. The distance from the neutral axis to the extreme fiber (y) is another critical factor influencing the maximum compressive stress. The stress varies linearly from the neutral axis, which experiences zero stress, to the extreme fibers, which experience the maximum stress. Therefore, a greater distance from the neutral axis means a higher stress. For a given cross-section, the distance 'y' is directly related to the overall dimensions of the section. For example, in a rectangular beam, 'y' is half of the height. Increasing the height of the beam will increase the distance 'y' and, consequently, the maximum compressive stress. However, increasing the dimensions of the section also affects the moment of inertia, which we will discuss next. The moment of inertia (I) is a geometric property that quantifies the resistance of a cross-section to bending. A higher moment of inertia indicates a greater resistance to bending, meaning the section can withstand larger bending moments without experiencing excessive stress. Therefore, increasing the moment of inertia will decrease the maximum compressive stress, and vice versa. The moment of inertia depends on the shape and dimensions of the cross-section. For example, a rectangular section has a moment of inertia of I = (b*h^3)/12, where 'b' is the width and 'h' is the height. From this formula, it's clear that the height has a more significant impact on the moment of inertia than the width, since it is raised to the power of 3. This means that increasing the height of a beam will significantly increase its resistance to bending and reduce the maximum compressive stress. The interplay between these three factors – bending moment, distance from the neutral axis, and moment of inertia – is crucial for understanding and managing bending stresses in structural design. Engineers must carefully consider these factors when selecting materials and dimensions for structural members to ensure they can withstand the applied loads without exceeding their allowable stresses. For example, if a structural member is expected to experience a high bending moment, engineers may choose to increase the moment of inertia by using a deeper section or by adding reinforcing elements. Alternatively, they may choose a material with a higher allowable stress to accommodate the bending stresses. In conclusion, calculating the maximum compressive stress is just one part of the larger picture. Understanding the factors that influence this stress and how they interact with each other is essential for designing safe, efficient, and durable structures. By mastering these concepts, engineers can confidently tackle a wide range of structural challenges and contribute to the development of innovative and sustainable solutions.
