Solving Y[n]=x[n]+2x[n-2]-5y[n-4] Difference Equation With DTFT

by Scholario Team 64 views

Introduction

Hey guys! Ever found yourself scratching your head over difference equations? These mathematical expressions pop up everywhere, from signal processing to economics, and tackling them can feel like cracking a tough code. But don't worry, we're here to break it down, especially when we throw the Discrete-Time Fourier Transform (DTFT) into the mix. Today, we're diving deep into a specific equation and figuring out how to solve it using this powerful tool. We'll also chat about what our solution actually means in the real world. Let's get started!

Understanding the Difference Equation

So, what's the equation we're tackling today? It's this beauty: y[n] = x[n] + 2x[n-2] - 5y[n-4]. Now, before you glaze over, let's dissect it. We're dealing with a system where the output at any given time (y[n]) depends on the current input (x[n]), some past inputs (x[n-2]), and even some past outputs (y[n-4]). Think of it like a recipe where you need a bit of what you're cooking now and a dash of what you cooked earlier to get the perfect dish. In this case, our input, x[n], is a sine wave: sin(π/2 * n). This is a rhythmic signal, oscillating nicely between -1 and 1. The challenge is to figure out what the output, y[n], looks like. This is where the magic of the DTFT comes in.

Difference equations are fundamental in various fields, including signal processing, control systems, and economics. They describe the relationship between the input and output of a system at discrete time intervals. In our case, the equation y[n] = x[n] + 2x[n-2] - 5y[n-4] represents a linear time-invariant (LTI) system. This means the system's behavior doesn't change over time, and it responds linearly to inputs. The DTFT is a powerful tool for analyzing LTI systems because it transforms the system's representation from the time domain to the frequency domain. This transformation often simplifies the analysis and solution of difference equations. By understanding the frequency components of the input and the system's response at different frequencies, we can predict the output behavior. This approach is particularly useful when dealing with complex systems where time-domain analysis might be cumbersome. The coefficients in the difference equation (1, 2, and -5) determine the system's characteristics, such as its stability and frequency response. Analyzing these coefficients in the frequency domain provides valuable insights into the system's behavior. For example, poles and zeros in the system's transfer function (which we'll derive using the DTFT) can indicate resonant frequencies and stability issues. In essence, solving this difference equation using the DTFT isn't just an academic exercise; it's a practical skill that allows engineers and scientists to design and analyze a wide range of systems, from audio filters to control algorithms.

The Discrete-Time Fourier Transform (DTFT) to the Rescue

The DTFT is like a superhero for signals. It takes a signal from the time domain – where we see how it changes over time – and transforms it into the frequency domain – where we see the different frequencies that make up the signal. Imagine it like shining a prism on white light and seeing the rainbow of colors. The DTFT does something similar for signals. Applying the DTFT to our difference equation lets us turn it into a simpler algebraic equation, which is much easier to solve. So, how does it work? We apply the DTFT to each term in the equation. Remember, the DTFT turns signals into functions of frequency, usually denoted by ω (omega). The key properties we'll use are:

  • DTFT(y[n]) = Y(ω)
  • DTFT(x[n]) = X(ω)
  • DTFT(x[n-k]) = e^(-jωk) * X(ω) (This is the time-shifting property, super important!)

The DTFT is a cornerstone of digital signal processing, providing a way to analyze and manipulate signals in the frequency domain. The fundamental idea behind the DTFT is to decompose a discrete-time signal into its constituent frequencies. This decomposition allows us to understand the signal's spectral content – which frequencies are present and their respective magnitudes and phases. The DTFT achieves this by representing the signal as a sum of complex exponentials, each corresponding to a specific frequency. The magnitude of each complex exponential indicates the amplitude of that frequency component, while the phase indicates its time shift. This frequency-domain representation is incredibly useful for various tasks, such as filtering, spectral analysis, and system identification. For instance, we can design filters to selectively attenuate or amplify certain frequency components in a signal. By examining the DTFT of a signal, we can identify dominant frequencies, noise sources, and other important characteristics. The time-shifting property of the DTFT is particularly crucial for solving difference equations. This property states that shifting a signal in the time domain corresponds to multiplying its DTFT by a complex exponential factor. This allows us to easily handle terms like x[n-2] and y[n-4] in our equation. By applying the DTFT and using its properties, we transform the difference equation from the time domain to the frequency domain, where it becomes an algebraic equation. Solving this algebraic equation for Y(ω) gives us the frequency response of the system, which tells us how the system responds to different frequencies. This is a key step in understanding the system's behavior and finding the solution y[n].

Solving in the Frequency Domain

Let's get our hands dirty! Applying the DTFT to our equation, y[n] = x[n] + 2x[n-2] - 5y[n-4], gives us:

Y(ω) = X(ω) + 2e^(-j2ω)X(ω) - 5e^(-j4ω)Y(ω)

See how the time shifts (n-2, n-4) turned into those exponential terms? Now, we need to isolate Y(ω). Let's move all the Y(ω) terms to one side:

Y(ω) + 5e^(-j4ω)Y(ω) = X(ω) + 2e^(-j2ω)X(ω)

Factor out Y(ω):

Y(ω) [1 + 5e^(-j4ω)] = X(ω) [1 + 2e^(-j2ω)]

Now, we can solve for Y(ω) by dividing both sides:

Y(ω) = X(ω) [1 + 2e^(-j2ω)] / [1 + 5e^(-j4ω)]

This is our system's transfer function in the frequency domain! It tells us how the system modifies different frequency components of the input. To find the output, we need to know X(ω), the DTFT of our input x[n] = sin(π/2 * n).

The transformation of the difference equation into the frequency domain is a pivotal step in solving it. By applying the DTFT, we convert the equation, which involves time-shifted terms, into an algebraic equation involving complex exponentials. This transformation significantly simplifies the problem because algebraic manipulations are generally easier to perform than time-domain operations on difference equations. The resulting equation, Y(ω) = X(ω) [1 + 2e^(-j2ω)] / [1 + 5e^(-j4ω)], expresses the output spectrum Y(ω) in terms of the input spectrum X(ω) and a frequency-dependent term. This term, [1 + 2e^(-j2ω)] / [1 + 5e^(-j4ω)], is known as the system's transfer function, often denoted as H(ω). The transfer function is a crucial concept in system analysis because it characterizes the system's response to different frequencies. It tells us how the system amplifies or attenuates each frequency component of the input signal. The numerator of the transfer function, 1 + 2e^(-j2ω), corresponds to the zeros of the system, while the denominator, 1 + 5e^(-j4ω), corresponds to the poles. The locations of these poles and zeros in the complex plane provide valuable information about the system's stability and frequency response characteristics. For example, poles close to the unit circle can indicate resonant frequencies or potential instability. To complete the solution, we need to determine X(ω), the DTFT of the input signal x[n] = sin(π/2 * n). This involves applying the DTFT to the sinusoidal input, which results in a pair of impulses in the frequency domain. Once we have X(ω), we can multiply it by the transfer function H(ω) to obtain Y(ω). The final step is to take the inverse DTFT of Y(ω) to get the output signal y[n] in the time domain. This process demonstrates the power of the DTFT in transforming complex time-domain problems into simpler frequency-domain problems.

Finding X(ω) for our sin(π/2 * n) Input

Okay, this is where things get a bit more specific. We know x[n] = sin(π/2 * n). The DTFT of a sine wave is a pair of impulses (or Dirac delta functions) in the frequency domain. Specifically, for x[n] = sin(ω₀n), the DTFT X(ω) has impulses at ω = ω₀ and ω = -ω₀. In our case, ω₀ = π/2. So, X(ω) will have impulses at ω = π/2 and ω = -π/2. The magnitude of these impulses is important too. For a sine wave with amplitude 1, the impulses have a magnitude of π/j (where j is the imaginary unit) and -π/j, respectively. So, we can write X(ω) as:

X(ω) = (π/j) [δ(ω - π/2) - δ(ω + π/2)]

This might look scary, but it just means we have spikes at these two frequencies. Now, we can plug this into our equation for Y(ω).

The DTFT of a sinusoidal signal is a fundamental result in signal processing, and understanding it is crucial for analyzing systems with sinusoidal inputs. The fact that the DTFT of a sine wave consists of impulses in the frequency domain reflects the fact that a pure sine wave contains only one frequency component. The location of these impulses corresponds to the frequency of the sine wave, while their magnitudes and phases indicate the amplitude and phase of the sine wave. In our case, the input signal x[n] = sin(π/2 * n) is a sine wave with a frequency of π/2 radians per sample. The DTFT of this signal, X(ω) = (π/j) [δ(ω - π/2) - δ(ω + π/2)], shows impulses at ω = π/2 and ω = -π/2. The impulses at positive and negative frequencies are a consequence of the DTFT's periodicity and the fact that the sine function is an odd function. The magnitude of the impulses, π/j and -π/j, indicates the amplitude and phase of the sine wave. The imaginary unit 'j' in the denominator reflects the fact that the sine wave is an odd function and has a phase shift of π/2 radians relative to a cosine wave. Now that we have the DTFT of the input signal, X(ω), we can substitute it into the equation for Y(ω) that we derived earlier. This substitution will allow us to determine the frequency-domain representation of the output signal. The next step involves multiplying X(ω) by the system's transfer function H(ω) to obtain Y(ω). This multiplication effectively filters the input signal by the system's frequency response. The resulting Y(ω) will show the frequency components present in the output signal, taking into account the system's characteristics. By understanding the DTFT of sinusoidal signals, we can effectively analyze and design systems that process these signals. This is particularly important in applications such as audio processing, communications, and control systems, where sinusoidal signals are frequently encountered.

Putting it Together and Finding y[n]

We have Y(ω) = X(ω) [1 + 2e^(-j2ω)] / [1 + 5e^(-j4ω)] and X(ω) = (π/j) [δ(ω - π/2) - δ(ω + π/2)]. Now we multiply them:

Y(ω) = (π/j) [δ(ω - π/2) - δ(ω + π/2)] * [1 + 2e^(-j2ω)] / [1 + 5e^(-j4ω)]

Because of the properties of the delta function, we only need to evaluate the rest of the expression at ω = π/2 and ω = -π/2:

Y(ω) = (π/j) [δ(ω - π/2) - δ(ω + π/2)] * [1 + 2e^(-jπ)] / [1 + 5e^(-j2π)]

Since e^(-jπ) = -1 and e^(-j2π) = 1, we get:

Y(ω) = (π/j) [δ(ω - π/2) - δ(ω + π/2)] * [1 - 2] / [1 + 5]

Y(ω) = (π/j) [δ(ω - π/2) - δ(ω + π/2)] * (-1/6)

Y(ω) = (-π/6j) [δ(ω - π/2) - δ(ω + π/2)]

Now, we need to take the inverse DTFT to get back to the time domain. Remember, the inverse DTFT of [δ(ω - ω₀) - δ(ω + ω₀)] is proportional to sin(ω₀n). So:

y[n] = (-1/6) sin(π/2 * n)

This is pretty close to the given answer! We just have a slightly different form. Let's see how they relate.

The process of combining the DTFT of the input signal with the system's transfer function is a crucial step in determining the output signal. By multiplying X(ω) with H(ω), we effectively filter the input signal by the system's frequency response. The result, Y(ω), represents the frequency-domain representation of the output signal. In our case, we have Y(ω) = (π/j) [δ(ω - π/2) - δ(ω + π/2)] * [1 + 2e^(-j2ω)] / [1 + 5e^(-j4ω)]. To simplify this expression, we utilize the sifting property of the Dirac delta function, which states that multiplying a function by a delta function and integrating over all frequencies is equivalent to evaluating the function at the location of the delta function. This property allows us to evaluate the term [1 + 2e^(-j2ω)] / [1 + 5e^(-j4ω)] only at the frequencies where the delta functions are non-zero, namely ω = π/2 and ω = -π/2. By substituting these values and simplifying the expression, we obtain Y(ω) = (-π/6j) [δ(ω - π/2) - δ(ω + π/2)]. This result indicates that the output signal also consists of impulses at frequencies π/2 and -π/2, similar to the input signal. However, the amplitude of these impulses is scaled by a factor of -1/6. To obtain the output signal in the time domain, we need to take the inverse DTFT of Y(ω). Recall that the inverse DTFT of a pair of impulses at ω = ω₀ and ω = -ω₀ is proportional to sin(ω₀n). Therefore, the inverse DTFT of Y(ω) is y[n] = (-1/6) sin(π/2 * n). This result shows that the output signal is a sine wave with the same frequency as the input signal but with a scaled amplitude and a phase shift. The scaling factor of -1/6 indicates that the system attenuates the input signal by a factor of 6 and inverts its polarity. This final step of taking the inverse DTFT allows us to transform the frequency-domain representation of the output signal back into the time domain, providing a complete solution to the difference equation.

Interpreting y[n] = (-1/6) sin(π/2 * n)

Our solution, y[n] = (-1/6) sin(π/2 * n), tells us a lot. First, the output is also a sine wave with the same frequency (π/2) as the input. This makes sense – our system is linear, so it doesn't create new frequencies. The key changes are in amplitude and phase. The amplitude is scaled by -1/6. This means the output sine wave is 1/6th the size of the input sine wave and is inverted (the negative sign). Now, let's compare this to the given form: y[n] = (1/6) sin(0.5nπ + π). Remember the trig identity: sin(x + π) = -sin(x). So, (1/6) sin(0.5nπ + π) = -(1/6) sin(0.5nπ) = (-1/6) sin(π/2 * n). It's the same answer! Just written slightly differently. The +π inside the sine function represents a phase shift of 180 degrees, which is the same as inverting the signal. So, both forms of the answer tell us that the output is a scaled and inverted version of the input sine wave.

Interpreting the solution y[n] = (-1/6) sin(π/2 * n) in the context of the original difference equation and the system it represents is crucial for understanding the system's behavior. The solution reveals that the system's output is a sinusoidal signal with the same frequency as the input signal (π/2 radians per sample) but with a reduced amplitude and a phase shift. The amplitude scaling factor of -1/6 indicates that the system attenuates the input signal by a factor of 6 and inverts its polarity. This attenuation and inversion are a direct consequence of the system's characteristics, as determined by the coefficients in the difference equation (1, 2, and -5). The fact that the output signal has the same frequency as the input signal is a characteristic of linear time-invariant (LTI) systems. LTI systems do not create new frequencies; they only modify the amplitude and phase of existing frequency components. The phase shift introduced by the system can be interpreted as a time delay or advance. In this case, the inversion of the signal corresponds to a phase shift of π radians (180 degrees). This means that the output signal is 180 degrees out of phase with the input signal. The solution can also be expressed in the form y[n] = (1/6) sin(0.5nπ + π), which is mathematically equivalent to y[n] = (-1/6) sin(π/2 * n). The +π term in the argument of the sine function represents the phase shift of π radians. This alternative form highlights the phase shift more explicitly. By analyzing the solution, we gain valuable insights into the system's behavior. We know that the system attenuates the input signal, inverts its polarity, and introduces a phase shift of π radians. These characteristics can be used to predict the system's response to other inputs and to design systems with desired properties. Understanding the relationship between the input and output signals in both the time and frequency domains is essential for analyzing and designing signal processing systems.

Conclusion

Guys, we did it! We successfully solved a difference equation using the DTFT. We transformed the equation into the frequency domain, solved for the output spectrum, and transformed back to the time domain. We even interpreted what our solution means. The key takeaway here is that the DTFT is a powerful tool for analyzing and solving linear time-invariant systems. It allows us to move from the time domain to the frequency domain, where many problems become much easier to handle. So, next time you see a difference equation, don't panic – think DTFT!
