Calculating Electrostatic Force In An Equilateral Triangle: A Physics Problem

by Scholario Team 78 views

Hey guys! Ever wondered how to calculate the electrostatic forces acting on a charge in an equilateral triangle? Let's dive into this interesting physics problem together! We'll break down the concepts, calculations, and everything in between. So, buckle up and let's get started!

Understanding the Problem: Electrostatic Forces in an Equilateral Triangle

In this scenario, we have an equilateral triangle hanging out in the air, each side measuring 30 cm. At vertices A and B, there are charges of +4 µC and -1.5 µC, respectively. And at vertex C, we have a charge of 2 * 10^-5 C. Our mission is to calculate the total electrostatic force acting on the charge at vertex C. To tackle this, we'll need to understand a few key concepts, including Coulomb's Law, the principle of superposition, and vector addition. First off, Coulomb's Law is the backbone of electrostatic force calculations. It states that the force between two point charges is directly proportional to the product of the magnitudes of the charges and inversely proportional to the square of the distance between them. Mathematically, this is expressed as F = k * |q1 * q2| / r^2, where F is the electrostatic force, k is Coulomb's constant (approximately 8.99 * 10^9 Nm2/C2), q1 and q2 are the magnitudes of the charges, and r is the distance between them. Understanding Coulomb's Law is fundamental because it allows us to quantify the interaction between charged particles. It tells us how strong the force will be based on the amount of charge and how far apart they are. The principle of superposition is equally crucial. When multiple charges exert forces on a single charge, the total force is the vector sum of the individual forces. This means we can't just add the magnitudes of the forces; we need to consider their directions as well. Each force acts independently, and their combined effect determines the net force. For example, if two forces are acting in opposite directions, the net force will be smaller than the sum of their magnitudes because they partially cancel each other out. In our triangle problem, the charge at C experiences forces from both the charges at A and B. We need to calculate each of these forces separately and then add them as vectors to find the total electrostatic force. Vector addition is the method we use to combine forces acting in different directions. Since force is a vector quantity (it has both magnitude and direction), we need to use vector addition to find the resultant force. There are several ways to add vectors, including graphical methods (such as the parallelogram method) and analytical methods (using components). In this problem, using components will be the most straightforward approach. We'll break each force into its horizontal (x) and vertical (y) components, add the components separately, and then use the Pythagorean theorem and trigonometry to find the magnitude and direction of the total force. Grasping these concepts is vital for solving a wide range of electrostatic problems. By applying Coulomb's Law, understanding superposition, and mastering vector addition, you can calculate the forces acting on charged particles in complex systems. These principles are not only essential in physics but also have applications in fields like electrical engineering, chemistry, and materials science. So, as we move forward with solving our equilateral triangle problem, keep these concepts at the forefront of your mind. They're the tools we'll use to break down the problem and find the solution. Next, we'll start applying these concepts to our specific problem, calculating the individual forces, and adding them together to find the total electrostatic force at vertex C. Stay tuned!

Step-by-Step Calculation of Electrostatic Forces

Okay, let's get our hands dirty with the calculations! To find the total electrostatic force at vertex C, we'll break it down into manageable steps. First, we'll calculate the electrostatic force between charges A and C (let's call it F_AC), and then we'll calculate the force between charges B and C (F_BC). After that, we'll add these forces vectorially to find the net force. Remember, guys, accuracy is key here, so let's take our time and double-check our work. The first step is to calculate the magnitude of the force F_AC. We'll use Coulomb's Law: F_AC = k * |q_A * q_C| / r^2. We know that k is approximately 8.99 * 10^9 Nm2/C2, q_A is +4 µC (which is 4 * 10^-6 C), q_C is 2 * 10^-5 C, and r is 30 cm (which we need to convert to meters, so it's 0.3 m). Plugging these values into the formula, we get: F_AC = (8.99 * 10^9 Nm2/C2) * |(4 * 10^-6 C) * (2 * 10^-5 C)| / (0.3 m)^2. Crunching the numbers, we find that F_AC ≈ 8 N. The force is repulsive because both charges are positive. Now, let's calculate the magnitude of the force F_BC. Again, we'll use Coulomb's Law: F_BC = k * |q_B * q_C| / r^2. This time, q_B is -1.5 µC (which is -1.5 * 10^-6 C), q_C is still 2 * 10^-5 C, and r remains 0.3 m. Plugging these values into the formula, we get: F_BC = (8.99 * 10^9 Nm2/C2) * |(-1.5 * 10^-6 C) * (2 * 10^-5 C)| / (0.3 m)^2. Calculating this gives us F_BC ≈ 3 N. The force is attractive because the charges have opposite signs. With the magnitudes of the forces calculated, we need to consider their directions. Since the triangle is equilateral, each angle is 60 degrees. The force F_AC acts along the line AC, and the force F_BC acts along the line BC. To add these forces vectorially, it's easiest to resolve them into their x and y components. This involves using trigonometry. For F_AC, the x-component is F_ACx = F_AC * cos(60°) = 8 N * 0.5 = 4 N, and the y-component is F_ACy = F_AC * sin(60°) = 8 N * √3/2 ≈ 6.93 N. For F_BC, the x-component is F_BCx = -F_BC * cos(60°) = -3 N * 0.5 = -1.5 N (negative because it acts in the opposite direction), and the y-component is F_BCy = F_BC * sin(60°) = 3 N * √3/2 ≈ 2.60 N. Now, we can add the components: Total x-component F_x = F_ACx + F_BCx = 4 N + (-1.5 N) = 2.5 N. Total y-component F_y = F_ACy + F_BCy = 6.93 N + 2.60 N = 9.53 N. Finally, to find the magnitude of the total force, we use the Pythagorean theorem: F_total = √(F_x^2 + F_y^2) = √((2.5 N)^2 + (9.53 N)^2) ≈ √(6.25 + 90.82) ≈ √97.07 ≈ 9.85 N. So, the magnitude of the total electrostatic force at vertex C is approximately 9.85 N. The direction can be found using the arctangent function: θ = arctan(F_y / F_x) = arctan(9.53 / 2.5) ≈ 75.3 degrees. This angle is relative to the horizontal axis. This step-by-step approach ensures that we've accounted for all the forces and their directions. Next, we'll put it all together in the conclusion.

Final Result: Total Electrostatic Force at Vertex C

Alright, guys, we've crunched the numbers and navigated through the physics! Let's bring it all together to state our final result. We set out to calculate the total electrostatic force acting on the charge at vertex C of our equilateral triangle. After meticulously applying Coulomb's Law, understanding the principle of superposition, and adding the forces vectorially, we've arrived at our answer. The magnitude of the total electrostatic force at vertex C is approximately 9.85 N. This is a significant force, indicating a strong interaction between the charges in our system. Remember, force is a vector quantity, so we also need to specify the direction. We found that the direction of the total force is approximately 75.3 degrees relative to the horizontal axis. This tells us not only how strong the force is but also which way it's pulling or pushing the charge at vertex C. To visualize this, imagine drawing an arrow with a length representing 9.85 N, pointing at an angle of 75.3 degrees from the horizontal. This arrow represents the net electrostatic force on the charge at C. The direction is crucial because it determines the overall effect on the charge. For instance, if the force were in the opposite direction, it would have a different impact on the charge's motion or equilibrium. This result is a testament to the power of electrostatic forces. Even with relatively small charges (on the order of microcoulombs), the forces can be substantial, especially when the distances are small (like our 30 cm sides). This is why electrostatics plays such a vital role in various phenomena, from the behavior of atoms and molecules to the operation of electronic devices. Understanding the magnitude and direction of the electrostatic force is essential for predicting the behavior of charged particles in electric fields. For example, if we were to release the charge at vertex C, it would accelerate in the direction of the net force we calculated. The acceleration would depend on the charge's mass and the magnitude of the force, as described by Newton's Second Law of Motion (F = ma). Moreover, this calculation has practical applications. Engineers use these principles to design and analyze electrical systems, ensuring that components can withstand the electrostatic forces they will encounter. In fields like materials science, understanding electrostatic interactions is crucial for designing new materials with specific electrical properties. So, there you have it! We've successfully calculated the total electrostatic force at vertex C. This problem highlights the importance of understanding fundamental physics principles and applying them systematically. I hope this breakdown has been helpful and has given you a clearer understanding of electrostatic forces. Keep exploring and keep questioning – that's where the real learning happens! Remember guys, physics isn't just about formulas; it's about understanding the world around us. By breaking down complex problems like this one, we gain a deeper appreciation for the forces that shape our universe.

Calculate the total electrostatic force at vertex C, given an equilateral triangle with sides of 30 cm, charges of +4 µC at A, -1.5 µC at B, and 2 * 10^-5 C at C.
