Calculate Total Capacitance In A Mixed Capacitor Circuit

Hey everyone! Today, we're diving into the fascinating world of capacitors and how they behave when connected in a mixed circuit. Specifically, we'll be tackling a problem involving three capacitors – Ca1 (3 pF), Ca2 (5 pF), and Ca3 (3 pF) – arranged in a combination of series and parallel connections. Understanding how to calculate total capacitance in such circuits is crucial for anyone working with electronics, so let's get started!

Understanding Capacitance and Capacitor Combinations

Before we jump into the calculation, let's quickly recap the basics of capacitance and how capacitors behave in series and parallel configurations. Capacitance, measured in picofarads (pF) in this case, is the ability of a capacitor to store electrical charge. Think of it like a tiny rechargeable battery! The higher the capacitance, the more charge the capacitor can store at a given voltage.

Now, when capacitors are connected in series, they form a single path for the charge to flow. This means the charge stored on each capacitor is the same, but the voltage across each capacitor may be different. The total capacitance in a series connection is always less than the smallest individual capacitance. This might seem counterintuitive, but it's because the effective distance between the plates of the capacitors increases, reducing the overall ability to store charge. The formula for calculating the total capacitance (${C_\text{total}}$) of capacitors in series is:

${\frac{1}{C_\text{total}} = \frac{1}{C_1} + \frac{1}{C_2} + \frac{1}{C_3} + ... }$

On the other hand, when capacitors are connected in parallel, they provide multiple paths for the charge to flow. This means the voltage across each capacitor is the same, but the charge stored on each capacitor may be different. The total capacitance in a parallel connection is simply the sum of the individual capacitances. This makes sense because connecting capacitors in parallel effectively increases the surface area available for charge storage. The formula for calculating the total capacitance (${C_\text{total}}$) of capacitors in parallel is:

${C_\text{total} = C_1 + C_2 + C_3 + ... }$

With these fundamental concepts in mind, we're well-equipped to tackle the mixed capacitor circuit problem.

Analyzing the Mixed Capacitor Circuit

Alright, let's break down the circuit configuration we're dealing with. We have three capacitors: Ca1 (3 pF), Ca2 (5 pF), and Ca3 (3 pF). The key here is that Ca1 and Ca3 are connected in series, and this series combination is then connected in parallel with Ca2. To find the total capacitance, we'll need to tackle this in two steps:

1. Calculate the equivalent capacitance of the series combination (Ca1 and Ca3).
2. Calculate the total capacitance of the parallel combination (the equivalent capacitance from step 1 and Ca2).

This step-by-step approach allows us to systematically simplify the circuit and arrive at the final answer. Remember, it's all about breaking down complex problems into smaller, more manageable parts!

Step 1: Series Combination (Ca1 and Ca3)

First, let's focus on Ca1 and Ca3, which are connected in series. We'll use the formula for series capacitance that we discussed earlier:

${\frac{1}{C_\text{series}} = \frac{1}{C_{a1}} + \frac{1}{C_{a3}} }$

Plugging in the values for Ca1 (3 pF) and Ca3 (3 pF), we get:

${\frac{1}{C_\text{series}} = \frac{1}{3 \text{ pF}} + \frac{1}{3 \text{ pF}} }$

${\frac{1}{C_\text{series}} = \frac{2}{3 \text{ pF}} }$

To find C_series, we take the reciprocal of both sides:

${C_\text{series} = \frac{3}{2} \text{ pF} = 1.5 \text{ pF} }$

So, the equivalent capacitance of the series combination of Ca1 and Ca3 is 1.5 pF. This means we can now treat this series combination as a single capacitor with a capacitance of 1.5 pF.

Step 2: Parallel Combination (C_series and Ca2)

Now that we've simplified the series part of the circuit, we're left with a parallel combination. We have the equivalent capacitance of the series combination (C_series = 1.5 pF) in parallel with Ca2 (5 pF). To find the total capacitance of this parallel combination, we simply add the capacitances:

${C_\text{total} = C_\text{series} + C_{a2} }$

Plugging in the values, we get:

${C_\text{total} = 1.5 \text{ pF} + 5 \text{ pF} }$

${C_\text{total} = 6.5 \text{ pF} }$

Therefore, the total capacitance of the mixed capacitor circuit is 6.5 pF.

Final Answer and Conclusion

So, guys, after carefully analyzing the circuit and performing the calculations, we've determined that the total capacitance of the mixed capacitor circuit is approximately 6.5 pF. This value wasn't explicitly provided in the original options, which might indicate a slight error in the options or the need for rounding based on significant figures. However, 6.5 pF is the most accurate answer based on our calculations.

Understanding how to calculate total capacitance in mixed circuits is a fundamental skill in electronics. By breaking down the circuit into series and parallel components, we can systematically apply the appropriate formulas and arrive at the correct answer. Remember, practice makes perfect, so keep working on these types of problems to solidify your understanding! This knowledge is super valuable for anyone working with circuit design, analysis, or troubleshooting. Keep learning and exploring the exciting world of electronics!
